Hardware

Included Power Adapter

Yes

Ethernet Port

8

Ethernet Port Speed

100 Mbps

Description of Function Slots

Port 1–8: 8 × 10/100 Base-T

Power Supply

5 VDC; 1 A

Operating Temperature

0 °C to +45 °C (+32 °F to +113 °F)

Operating Humidity

5%–95% (RH)

Storage Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Storage Humidity

5%–95% (RH)

Power Consumption

Idling: 0.1 W;
Full load: 0.75 W

Performance

MTBF

929.51 years

Switching Capacity

1.6 Gbit

Packet Forwarding Rate

1.1904 Mpps

Packet Buffer Size

768 kbit

MAC Table Size

2K

General

Statics Protection

Air discharge: 8 kV
Contact discharge: 4 kV

Lighting Protection

Common mode: 2 kV

Net Weight

0.16 kg (0.35 lb)

Gross Weight

0.29 kg (0.64 lb)

Product Dimensions

132.9 mm × 62.4 mm × 24.0 mm
(5.23″ × 2.46″ × 0.94″)

Packaging Dimensions

136.0 mm × 55.0 mm × 153.0 mm
(5.35″ × 2.17″ × 6.02″)

Casing Material

Plastic

Installation

Desktop mount

Certifications

CE; FCC
